MSI MAG B650 Tomahawk WiFi
MSI MAG B650 Tomahawk WiFi is a ATX board for AM5 processors on the B650 chipset.
- Key fit specifications
- Socket: AM5 · Chipset: B650 · Form factor: ATX
- Good fit for
- Builds that plan a processor upgrade on the same board
- Know before buying
- PCIe 5.0 drives run at PCIe 4.0 speeds in these M.2 slots
Store availability
No active offer
No partner store currently has a verified offer for this model. You can still compare it, check compatibility and use it in a saved build.
Price history1 verified partner observations Authorized live dataView chart +
Not enough price observations yet to draw a history for this product.
Key specifications
The values most likely to affect compatibility and comparison.
- Socket
- AM5
- Chipset
- B650
- Form factor
- ATX
- Memory generation
- DDR5
More specifications (10)Open +
- Memory slots
- 4
- Maximum memory
- 256 GB
- Maximum memory speed
- 7600 MT/s
- M.2 slots
- 3
- M.2 max PCIe generation
- 4
- SATA ports
- 6
- Primary PCIe slot generation
- 4
- VRM tier
- Enhanced
- Wi-Fi
- Yes
- Launch year
- 2022
Compatible parts
Parts in the current catalog that can be paired with this model.
CPU9 of 20 compatibleReview +
Works with AMD Ryzen 5 7600, AMD Ryzen 5 7600X, AMD Ryzen 5 9600X and 6 more.
AMD Ryzen 5 5600 uses socket AM4 but MSI MAG B650 Tomahawk WiFi provides socket AM5.
AMD Ryzen 7 5700X3D uses socket AM4 but MSI MAG B650 Tomahawk WiFi provides socket AM5.
Intel Core i5-12400F uses socket LGA1700 but MSI MAG B650 Tomahawk WiFi provides socket AM5.
Memory16 of 22 compatibleReview +
Works with Corsair Vengeance 32GB (2x16GB) DDR5-6000 CL30, Corsair Vengeance 64GB (2x32GB) DDR5-6000 CL30, Corsair Vengeance RGB 32GB (2x16GB) DDR5-6000 CL30 and 13 more.
Corsair Vengeance LPX 16GB (2x8GB) DDR4-3200 CL16 is DDR4 but MSI MAG B650 Tomahawk WiFi accepts DDR5 only.
Corsair Vengeance LPX 32GB (2x16GB) DDR4-3600 CL18 is DDR4 but MSI MAG B650 Tomahawk WiFi accepts DDR5 only.
G.Skill Ripjaws V 32GB (2x16GB) DDR4-3600 CL16 is DDR4 but MSI MAG B650 Tomahawk WiFi accepts DDR5 only.
Case36 of 38 compatibleReview +
Works with be quiet! Dark Base 700 Black, be quiet! Dark Base 701 Black, be quiet! Dark Base Pro 901 Black and 33 more.
ASUS Prime AP201 accepts microATX, Mini-ITX boards, not ATX.
Cooler Master MasterBox NR200P accepts Mini-ITX boards, not ATX.
Storage44 of 44 compatibleReview +
Works with Corsair MP700 PRO 2TB, Crucial MX500 2TB, Crucial P310 2TB and 41 more.
Corsair MP700 PRO 2TB is a PCIe 5.0 drive in a PCIe 4.0 slot. It works, capped near 7 400 MB/s instead of 12400 MB/s.
Crucial T705 2TB is a PCIe 5.0 drive in a PCIe 4.0 slot. It works, capped near 7 400 MB/s instead of 14500 MB/s.
Samsung 9100 PRO 2TB is a PCIe 5.0 drive in a PCIe 4.0 slot. It works, capped near 7 400 MB/s instead of 14700 MB/s.
Exact models and identifiers1 exact configuration · useful when checking a store listingOpen +
| Configuration | Exact identity | Offers | Best known total |
|---|---|---|---|
| Default configurationDefault family configuration | GTIN 4711377010153MPN MAG B650 TOMAHAWK WIFI | 0 | — |
