MSI MAG B760 Tomahawk WiFi DDR5
MSI MAG B760 Tomahawk WiFi DDR5 is a ATX board for LGA1700 processors on the B760 chipset.
- Key fit specifications
- Socket: LGA1700 · Chipset: B760 · Form factor: ATX
- Good fit for
- Cost-controlled builds that will be replaced whole rather than upgraded
- Know before buying
- PCIe 5.0 drives run at PCIe 4.0 speeds in these M.2 slots
Store availability
No active offer
No partner store currently has a verified offer for this model. You can still compare it, check compatibility and use it in a saved build.
Price history33 verified partner observations Authorized live dataView chart +
- Price position
- Building evidence
- Current percentile
- —
- Observed trend
- Stable +2.8%
- Typical range
- $319–$325
- Observed low
- $319
- Median
- $319
- Observed high
- $331
- Dispersion
- 1.9% IQR / median
Orange marks the current item price; the grey band is the middle 50% of observations and the dashed line is the median. Every point comes from authorized retailer observations.
Key specifications
The values most likely to affect compatibility and comparison.
- Socket
- LGA1700
- Chipset
- B760
- Form factor
- ATX
- Memory generation
- DDR5
More specifications (10)Open +
- Memory slots
- 4
- Maximum memory
- 192 GB
- Maximum memory speed
- 7000 MT/s
- M.2 slots
- 3
- M.2 max PCIe generation
- 4
- SATA ports
- 4
- Primary PCIe slot generation
- 5
- VRM tier
- Enhanced
- Wi-Fi
- Yes
- Launch year
- 2023
Compatible parts
Parts in the current catalog that can be paired with this model.
CPU7 of 20 compatibleReview +
Works with Intel Core i5-12400F, Intel Core i5-13400F, Intel Core i5-13600K and 4 more.
AMD Ryzen 5 5600 uses socket AM4 but MSI MAG B760 Tomahawk WiFi DDR5 provides socket LGA1700.
AMD Ryzen 5 7600 uses socket AM5 but MSI MAG B760 Tomahawk WiFi DDR5 provides socket LGA1700.
AMD Ryzen 5 7600X uses socket AM5 but MSI MAG B760 Tomahawk WiFi DDR5 provides socket LGA1700.
Memory16 of 22 compatibleReview +
Works with Corsair Vengeance 32GB (2x16GB) DDR5-6000 CL30, Corsair Vengeance 64GB (2x32GB) DDR5-6000 CL30, Corsair Vengeance RGB 32GB (2x16GB) DDR5-6000 CL30 and 13 more.
The 7200 MT/s kit will run at up to 7000 MT/s on this platform.
The 7200 MT/s kit will run at up to 7000 MT/s on this platform.
Corsair Vengeance LPX 16GB (2x8GB) DDR4-3200 CL16 is DDR4 but MSI MAG B760 Tomahawk WiFi DDR5 accepts DDR5 only.
Corsair Vengeance LPX 32GB (2x16GB) DDR4-3600 CL18 is DDR4 but MSI MAG B760 Tomahawk WiFi DDR5 accepts DDR5 only.
G.Skill Ripjaws V 32GB (2x16GB) DDR4-3600 CL16 is DDR4 but MSI MAG B760 Tomahawk WiFi DDR5 accepts DDR5 only.
Case36 of 38 compatibleReview +
Works with be quiet! Dark Base 700 Black, be quiet! Dark Base 701 Black, be quiet! Dark Base Pro 901 Black and 33 more.
ASUS Prime AP201 accepts microATX, Mini-ITX boards, not ATX.
Cooler Master MasterBox NR200P accepts Mini-ITX boards, not ATX.
Storage44 of 44 compatibleReview +
Works with Corsair MP700 PRO 2TB, Crucial MX500 2TB, Crucial P310 2TB and 41 more.
Corsair MP700 PRO 2TB is a PCIe 5.0 drive in a PCIe 4.0 slot. It works, capped near 7 400 MB/s instead of 12400 MB/s.
Crucial T705 2TB is a PCIe 5.0 drive in a PCIe 4.0 slot. It works, capped near 7 400 MB/s instead of 14500 MB/s.
Samsung 9100 PRO 2TB is a PCIe 5.0 drive in a PCIe 4.0 slot. It works, capped near 7 400 MB/s instead of 14700 MB/s.
Exact models and identifiers1 exact configuration · useful when checking a store listingOpen +
| Configuration | Exact identity | Offers | Best known total |
|---|---|---|---|
| Default configurationDefault family configuration | GTIN 4711377034210MPN MAG B760 TOMAHAWK WIFI | 0 | — |
Source details16 field-level source claims, retrieval dates and confidence valuesOpen +
| Field | Source | Retrieved | Confidence |
|---|---|---|---|
biosUpdateRequiredForCpus | Rigwise curated manufacturer catalog | Aug 12, 2026 | 98% |
chipset | Rigwise curated manufacturer catalog | Aug 12, 2026 | 95% |
formFactor | Rigwise curated manufacturer catalog | Aug 12, 2026 | 95% |
launchYear | Rigwise curated manufacturer catalog | Aug 12, 2026 | 95% |
m2MaxPcieGen | Rigwise curated manufacturer catalog | Aug 12, 2026 | 95% |
m2Slots | Rigwise curated manufacturer catalog | Aug 12, 2026 | 95% |
maxMemoryGb | Rigwise curated manufacturer catalog | Aug 12, 2026 | 95% |
maxMemoryMts | Rigwise curated manufacturer catalog | Aug 12, 2026 | 95% |
memoryGeneration | Rigwise curated manufacturer catalog | Aug 12, 2026 | 95% |
memorySlots | Rigwise curated manufacturer catalog | Aug 12, 2026 | 95% |
pcieSlotGen | Rigwise curated manufacturer catalog | Aug 12, 2026 | 95% |
platformLongevityIndex | Rigwise curated manufacturer catalog | Aug 12, 2026 | 95% |
sataPorts | Rigwise curated manufacturer catalog | Aug 12, 2026 | 95% |
socket | Rigwise curated manufacturer catalog | Aug 12, 2026 | 95% |
vrmTier | Rigwise curated manufacturer catalog | Aug 12, 2026 | 95% |
wifi | Rigwise curated manufacturer catalog | Aug 12, 2026 | 95% |
